Swit

PB-H290S 290Wh Intelligent Bi-voltage Battery Pack (SPECIAL ORDER)

SKU: SWI-PB-H290S

£665.99 £739.99 SAVE:£74.00
On Sale

Tax included. Shipping calculated at checkout.

  • Special Order Available. Estimate Delivery Date: 3-7 Working Days (Subject to Change)
  • Looking to hire? - More Info
Add Accessories:
£282.59 £313.99
£139.49 £154.99
£1,969.44 £2,316.99
Your Total:
  • Special Order Available. Estimate Delivery Date: 3-7 Working Days (Subject to Change)
  • Verified Secure Shopping

The SWIT PB-H290S Intelligent Bi-voltage V-Lock Battery Pack is the perfect solution for powering high-voltage cameras like the ARRI Alexa LF/65. It offers both 11-16.8V normal voltage and 22-33.6V high voltage output with automatic recognition and switching. Compatible with Alexa LF/65 and other cameras, which eliminates the risk of incorrect usage.

14.4V/28.8V Auto-Switching

The PB-H290S Bi-voltage battery has a default voltage range of 11-16.8V, making it compatible with standard V-mount cameras and chargers. By using the dedicated V-mount plate KA-A20S from ARRI, the battery can automatically switch to a higher voltage range of 22-33.6V, providing power for Alexa LF/65/SXT/AMIRA cameras.

* KA-A20S Plate: CNC metal housing, High load power pins, D-tapx2 (16V), 2-pin LEMO (16V), USBx1 (5V/2A) Officially Recommended by ARRI

14.4V/28.8V Auto-Switching

Along with ALEXA cameras, multiple Cine Lights are also equipped with high voltage input to efficiently decrease current. This safeguards power pins and guarantees dependability. Simply place a "Magic Sticker" on the specified location of standard V-mount plates and the PB-H290S battery will automatically switch to 22-33.6V output mode.

6A Super Fast Charging

The PB-H290S is compatible with the SWIT S-3812S or PC-P460S super-fast chargers, allowing for 6A fast charging. This can save up to 60% of charging time, with the ability to reach 80% charge in just 2 and a half hours and fully charge in 3 hours and 50 minutes.

D-Tap Socket

This battery pack features a D-Tap DC output socket on the top side, allowing it to also power other devices and accessories that feature a D-Tap power connector

  • Under 14.4V (11-16.8V) output mode, D-tap output 11-16.8V and Max load 120W/10A;
  • Under 28.8V (22-33.6V) output mode, D-tap output constant 16V and Max load 50W/3A;

Shock Proof

The SWIT PB-H290S features an innovative dual housing structure, where its inner cell cage and outer anti-shock housing with rubber covers. The new structure makes the battery highlight-robust, and resistant to impact damage. It can survive drops from up to 1.5 metres off the ground, at any angle.

Please note, from 4th September 2024, due to the unique design & packaging of this product, this item will feature a 14-day return Period if it remains unopened & in its sealed packaging. Once this item has been unsealed and opened, it is no longer covered by our returns policy.

Please note, this particular product is part of our “Special Order” selection, so we may not hold stock for this, and is placed to order. If you are interested in this item, you can place this order as a Pre-Order, and we will Special Order your product directly from the manufacturer. This should take approximately 3-7 working days to be delivered, but please note this is subject to change.

Approximate Battery Usage Times

PiXAPRO
LED200B MKIII 1 Hour, 27 Minutes
VNIX1500S 3 Hour, 13 Minutes & 12 Seconds
VNIX1500B 6 Hours, 26 Minutes & 24 Seconds
LECO1000B MKII 2 Hours, 54 Minutes
LECO1500B MKII 1 Hour, 55 Minutes & 48 Seconds
Godox
VL150II 1 Hour, 45 Minutes
UL60 4 Hours, 49 Minutes & 48 Seconds
UL60BI 3 Hours, 42 Minutes & 36 Seconds
UL150 1 Hour, 55 Minutes & 48 Seconds
UL150II 1 Hour, 48 Minutes & 36 Seconds
UL150IIBI 1 Hour, 52 Minutes & 12 Seconds
ML60IIBI (With AK-B02) 4 Hours, 49 Minutes & 48 Seconds
ML100BI (With AK-B02) 2 Hours, 24 Minutes & 26 Seconds
S60 4 Hours, 49 Minutes & 48 Seconds
S60BI 4 Hours, 49 Minutes & 48 Seconds
FL60 4 Hours, 49 Minutes & 48 Seconds
FL100 2 Hours, 54 Minutes
FL150R 1 Hour, 55 Minutes & 48 Seconds
FL150S 1 Hour, 55 Minutes & 48 Seconds
LD75R 3 Hours, 51 Minutes & 36 Seconds
LD150R 1 Hour, 55 Minutes & 48 Seconds
LD150RS 1 Hour, 55 Minutes & 48 Seconds
KNOWLED
M200D 1 Hour, 15 Minutes & 36 Seconds
M200BI 1 Hour, 15 Minutes & 36 Seconds
F200BI 1 Hour, 27 Minutes
AT200BI 1 Hour, 22 Minutes & 48 Seconds

Features

  • 14.4V/28.8V Bi-voltage auto switch
  • For ALEXA LF/65 high voltage cameras
  • For all normal voltage cameras
  • For high voltage cine lights
  • Compatible with normal voltage chargers
  • 290Wh capacity, at least 250W high load
  • 6A fast charging support
  • 8-LED remaining time indicators
  • D-tap power output socket
  • Normal V-mount connection
  • 1.5m drop-off proof, IP54 water proof
  • Multiple circuit protections

What’s In the Box

  • 1x PB-H290S V-Lock Battery

Specifications

Nominal Voltage14.4V or 28.8V auto switching
Capacity290Wh
Max output power (14.4V)Total: 250W
Pins: 250W / 20A
D-tap: 120W / 10A
Max output power (28.8V)Total: 250W
Pins: 250W / 10A
D-tap (16V): 50W / 3A
Max charging current16.8V / 10A
Mount TypeV-mount
Charging Temperature0 ~ 40°C
Discharging Temperature-20°C ~ 50°C(Capacity and Max Load may decrease when operating below 0°)
Dimension162×101×69mm
Net weight1578g
Manufacturer Code
PB-H290S
